domingo, 11 de outubro de 2015

Zenit TTL (1977-1985)

Zenit TTL

Esta fotografia é do exemplar que possuo.

Câmara gentilmente oferecida por Ida Brandão.


The Zenit TTL is a 35mm film SLR camera made by KMZ and produced between 1977-85 with quantity of 1.632.212 units. It is also made by MMZ (BelOMO) and produced between 1980-82 with quantity of 1.000.000 units. It belongs to the long lasting Zenit series.

It was an upgraded version of the Zenit EM, adding stop-down TTL metering and a rewind crank in place of the knob. The meter is not voltage sensitive and will work fine with a 1.5 volt alkaline battery.

The viewfinder is blue-tinted and comparatively dim and small (cf. the 'brilliant'-type Zenit E). The central portion of the viewfinder screen has a micro prism in the middle surrounded by a clear matte area.

The camera was also sold by Cambridge Camera Exchange in the U.S. under the label Cambron TTL.

Fonte: Camerapedia

This camera is a Zenit-EM with a TTL meter. The meter is a Match the needle type with a circle between a + and a -. The Zenit-TTL was available with chrome top (several variants of early KMZ with TTL in Cyrillic and later BeLomo) and completely black.

Produced: 1976-1985
Name: „Зенит-TTL“
Producer: KMZ
Frame size: 24x36.
Lens: Helios-44M  2/58.
Shutter: 1/30s-1/500s + B.

Quantity: 1.632.212 units.

Fonte: Sovietcams


A minha é uma PM4725 (ver Sovietcams):  The most common version of Zenit-TTL camera. The new style of selftimer lever. Shutter advance, shutter speeds and film rewind heads are new style already. 4 screws in a lensmount already. An earliest so far known camera has s/n #78079809 (Molotok 2008). Some cameras have soviet "Sign of Quality" on an accessory shoe.

A minha tem o n.º de série 80204573, o que parece indicar que foi fabricada em 1980 pela KMZ.

Manual em inglês

Parte 1 (html)
Parte 2 (html)
Outra versão

Sítios de referência



Kodacolor VR Plus 200/36

Fotografias tiradas com esta máquina

Zenit TTL - amostra 1

Zenit TTL - amostra 2
